Much Solar 12V 200AH Lone Life Deep Cycle Solar AGM Lead Acid Gel Battery MH 12-200

Description

Key Features :
♦Gelled electrolyte made by mixing sulfuric acid with silica fume.
♦The electrolyte is gel like ,immobile and does not leak ,enabling
uniform reaction of each part of the plate .
♦High rate discharge performance due to tight assembly technology
♦Strong heat dissipation and wide operating temperature range
♦Avoid acid mist being separated out , environment friendliness
♦Efficient venting system release excessive gas automatically

Applications :
♦EPS and UPS battery backup
♦Solar and wind energy storage system
♦Telecommunication Equipment
♦Power plant and transmission system
♦Signal system , emergency lighting system , security system

Parameter

Model:MH 12V 200AH
Capacity:200Ah
Dimensions(mm): 522 x 240 x 219 x 240
Container Material:ABS
Weight:50 Kg
Warranty (months):36 Months
Customized Packing & Brand Name:Yes
OEM & ODM Service:Yes

Much Solar 12V 200AH Agm Battery Functional Parameter
Model MH 12V 200AH 5. Environment Temperature
Nominal Voltage  12V Discharge Temperature  -20~60℃
Nominal Capacity (10 hour rate) 200Ah Charge Temperature  0~50℃
Number of Cells  6cells  Storage Temperature  -20~60℃
2. Rated Capacity at 25℃ (77° F) 6. Inner Resistance & Max . Discharge Current
10 hour rate (0.1C, 10.8V) 200Ah Fully Charged battery at 25℃ (77° F) 3.5mΩ
3 hour rate (0.25C, 10.8V) 144.7Ah Max. Discharge Current  3000A (5s)
1 hour rate (0.55C, 10.5V) 110.1Ah Short Circuit Current  10000A
3. Capacity affected by Temperature (10 hour rate) 7. Self-discharge  at 25℃ (77° F)
40℃   (104° F) 103% Capacity after 3 month storage  91%
25℃   (77° F) 100% Capacity after 6 month storage 82%
0℃    (32° F) 85% Capacity after 9 month storage 73%
-15℃   (5° F) 65% Capacity after 12 month storage 64%
4. Dimension and Weight  8. Constant voltage charging at 25℃ (77° F)
Length  522mm Cyclic use 14.4~14.9V
Width 240mm Maximum charging current  50A
Height  219mm Temperature compensation  -30mV/℃
Total Height  223mm Float use  13.6~13.8V
Reference Weight  50kg Temperature compensation  -20mV/℃
